6.824-lab1总结

前言

lab1是实现一个MapReduce，markdown写了挺久了，一直没有上传到博客

RPC定义

type HeartbeatArgs struct {
}

type HeartbeatReply struct {
    Filename string // map阶段使用
    JobType  JobType
    Id       int // map阶段传mapId, reduce阶段传reduceId
    NReduce  int // map阶段使用
    NMap     int // reduce阶段使用
}

type JobFinishArgs struct {
    Id       int
    JobPhase CurrentPhase
}

type JobFinishReply struct {
}

Tasks结构

Coordinator维护一个task列表，初始时为map task列表，当map阶段结束，task列表变更为reduce task

type Task struct {
    taskId     int // 当前taskId, map阶段为mapId, reduce阶段为reduceId
    startTime  time.Time
    taskStatus TaskStatus
    fileName   string
    jobType    JobType
}

Coordinator结构

type Coordinator struct {
    // Your definitions here.
    nMap         int          // 输入文件数量
    nReduce      int          // 参数传入
    files        []string     // 要处理的文件,map阶段通过reply传递给worker
    currentPhase CurrentPhase // 判断当前处于 map阶段 or reduce阶段 or all down阶段
    tasks        []Task

    mu sync.Mutex
}

Coordinator初始化：

func MakeCoordinator(files []string, nReduce int) *Coordinator {
    c := Coordinator{
        mu:      sync.Mutex{},
        files:   files,
        nMap:    len(files),
        nReduce: nReduce,
    }
    c.currentPhase = MapPhase
    c.tasks = make([]Task, c.nMap)
    for index, file := range c.files {
        c.tasks[index] = Task{
            fileName:   file,
            taskId:     index,
            taskStatus: Idle,
        }
    }

    c.server()
    return &c
}

RPC接口实现

我没有在Coordinator维护每个Worker的状态，每次收到Worker的请求时，Coordinator首先判断当前是什么phase，检查task完成情况。遍历task列表，当有空闲或者超时未完成的task时，将这个task分配给发起请求的worker。

1、当所有的ReduceTask都完成时，返回一个CompleteJob，worker收到后返回，MapReduce结束

2、如果当前所有的task都在处理中，判断是否有超时的task。如果有，重设其超时时间，并将这个task分配给请求的worker；如果没有，返回一个waitJob，worker收到后休眠一段时间，然后才重新发起请求

3、当有task空闲时，直接分配即可。

func (c *Coordinator) Request(args *HeartbeatArgs, reply *HeartbeatReply) error {
    c.mu.Lock()
    defer c.mu.Unlock()
    switch c.currentPhase {
    case AllDonePhase:
        reply.JobType = CompleteJob
    case MapPhase:
        c.selectTask(reply, MapPhase)
    case ReducePhase:
        c.selectTask(reply, ReducePhase)
    }
    // log.Printf("Coordinator: assign a task %v to worker", reply)
    return nil
}

func (c *Coordinator) selectTask(reply *HeartbeatReply, phase CurrentPhase) {
    hasNewJob := false
    var taskLen int
    if phase == MapPhase {
        taskLen = len(c.files)
    } else if phase == ReducePhase {
        taskLen = c.nReduce
    }
    for i := 0; i < taskLen; i++ {
        task := &c.tasks[i]
        if task.taskStatus == Idle {
            hasNewJob = true
            task.taskStatus = Processing
            task.startTime = time.Now()

            reply.Id = task.taskId
            reply.NMap = c.nMap
            reply.NReduce = c.nReduce
            reply.JobType = task.jobType
            // reduce阶段，filename直接在worker里根据mr-x-x的格式组装，用不到这个字段
            reply.Filename = task.fileName
            break
        } else if task.taskStatus == Processing {
            // task[i]超时未完成，需要把它交给其他worker处理
            if time.Now().Sub(task.startTime) > time.Second*10 {
                hasNewJob = true

                reply.Id = task.taskId
                reply.NMap = c.nMap
                reply.NReduce = c.nReduce
                reply.JobType = task.jobType

                reply.Filename = task.fileName

                task.startTime = time.Now()
            // log.Printf("Coordinator: a worker timeout, assign this task %v to another worker", reply)
                break
            }
        } else if task.taskStatus == Finished {
            continue
        } else {
            fmt.Errorf("unexcepted branch")
        }
    }

    if !hasNewJob {
        reply.JobType = WaitJob
    }
    return

}

Worker完成一个job时通知Coordinator，Coordinator将对应的task标记为已完成，并判断当前阶段所有任务是否已完成，如果完成了则进行下一阶段的初始化。

func (c *Coordinator) Report(args *JobFinishArgs, reply *JobFinishReply) error {
    c.mu.Lock()
    defer c.mu.Unlock()
    if c.currentPhase == AllDonePhase {
        return nil
    }
    if args.JobPhase == c.currentPhase {
        // log.Printf("Coordinator: Worker has completed a %v task %v \n", args.JobPhase, args)
        c.tasks[args.Id].taskStatus = Finished
        if c.IsAllTaskFinish() {
            if c.currentPhase == MapPhase {
                // log.Printf("Coordinator: MapPhase finish, start init ReducePhase")
                c.ReducePhaseInit()
                return nil
            } else if c.currentPhase == ReducePhase {
                // log.Printf("Coordinator: ReducePhase finish, nothing need to do!")
                c.currentPhase = AllDonePhase
                return nil
            } else {
                fmt.Errorf("report: unexcepted branch")
            }
        }

    }
    return nil
}
func (c *Coordinator) IsAllTaskFinish() bool {
    allFinish := true
    for i := 0; i < len(c.tasks); i++ {
        if c.tasks[i].taskStatus != Finished {
            allFinish = false
            break
        }
    }
    return allFinish
}

func (c *Coordinator) ReducePhaseInit() {
    c.currentPhase = ReducePhase
    c.tasks = make([]Task, c.nReduce)
    for i := 0; i < c.nReduce; i++ {
        c.tasks[i].taskId = i
        c.tasks[i].taskStatus = Idle
        c.tasks[i].jobType = ReduceJob
    }
}

Worker实现

Worker上的一个job对应于一个Coordinator的task（尽管可能有一个或多个超时的job对应于一个task，但只需要最后有一个Worker上的job完成并顺利report了就ok）

Worker收到回复后就根据JobType执行相应的操作，以map阶段为例：

/*
worker收到master的reply后，如果拿到一份mapJob，打开reply里指定了文件名的文件,
读取文件内容,以单词计数为例,调用mapf函数处理文件内容得到形如
add 1
apple 2
bad 2
这样的键值对数组（[]KeyValue），再将其中的键值对按哈希值写入不同的中间文件mr-x-x,前者为mapId, 由reply指定，
后者由ihash(key) % NReduce得出, NReduce由master设置为固定大小，本lab设置为输入文件数量
*/
func doMapJob(reply *HeartbeatReply, mapf func(string, string) []KeyValue) {
   fileName := reply.Filename
   content, err := os.ReadFile(fileName)
   if err != nil {
      log.Fatalf("cannot read %v", fileName)
   }
   kva := mapf(fileName, string(content))
   intermediates := make([][]KeyValue, reply.NReduce)
   for _, kv := range kva {
      index := ihash(kv.Key) % reply.NReduce
      intermediates[index] = append(intermediates[index], kv)
   }
   var wg sync.WaitGroup
   for index, intermediate := range intermediates {
      wg.Add(1)
      go func(index int, intermediate []KeyValue) {
         defer wg.Done()
         intermediateFilePath := generateMapResultFileName(reply.Id, index)
         tmpFile, err := os.CreateTemp(".", intermediateFilePath)
         if err != nil {
            log.Fatalf("cannot create tmp file %v", intermediateFilePath)
         }
         enc := json.NewEncoder(tmpFile)
         for _, kv := range intermediate {
            err := enc.Encode(&kv)
            if err != nil {
               log.Fatalf("cannot encode json %v", kv.Key)
            }
         }
         if err := os.Rename(tmpFile.Name(), intermediateFilePath); err != nil {
            fmt.Errorf("cannot replace %q with tempfile %q: %v",
               intermediateFilePath, tmpFile.Name(), err)
         }
      }(index, intermediate)
   }
   wg.Wait()
   reportTask(JobFinishArgs{reply.Id, MapPhase})

}

本lab的MapReduce是单机版的，文件其实都存在本地，所以不需要维护中间文件名，只需要在启动时根据mr-x-x的格式读取文件即可

func doReduceJob(reply *HeartbeatReply, reducef func(string, []string) string) {
   var kva []KeyValue
   for i := 0; i < reply.NMap; i++ {
      filePath := generateMapResultFileName(i, reply.Id)
      file, err := os.Open(filePath)
      if err != nil {
         log.Fatalf("cannot open %v", filePath)
      }
      dec := json.NewDecoder(file)
      for {
         var kv KeyValue
         if err := dec.Decode(&kv); err != nil {
            break
         }
         kva = append(kva, kv)
      }
      file.Close()
   }
   results := make(map[string][]string)
   for _, kv := range kva {
      results[kv.Key] = append(results[kv.Key], kv.Value)
   }

   reduceFileName := generateReduceResultFileName(reply.Id)
   tmpFile, err := os.CreateTemp(".", reduceFileName)
   if err != nil {
      log.Fatalf("cannot create tmp file %v", reduceFileName)
   }
   for key, values := range results {
      output := reducef(key, values)
      fmt.Fprintf(tmpFile, "%v %v\n", key, output)
   }
   if err := os.Rename(tmpFile.Name(), reduceFileName); err != nil {
      fmt.Errorf("cannot replace %q with tempfile %q: %v",
         reduceFileName, tmpFile.Name(), err)
   }
   reportTask(JobFinishArgs{reply.Id, ReducePhase})
}
